SIBATA Liquid Phase Organic Synthesizer Model CP-300 basic type body set
Add to Wishlist
* 1 If you use a 120ml and 500ml container, an optional heated block adapter is required. * 2 In order to control the temperature with room temperature plus 10 ° C or less, it is necessary to connect to an optional low -temperature circulation aquarium. *
Availability:
Out of stock
Contact for a quote.
Request for Quotationช่องทางการสั่งซื้ออื่น ๆ
ติดต่อทาง Line
@santatech
ติดต่อทางอีเมล์
[email protected]
ติดต่อทางโทรศัพท์
02-1013454
Description
| Item Code | 054300-3200 |
|---|---|
| Model | CP-300 |
| Set item name | CP-300 body set 200ml |
| Connection | Outer diameter φ10.5mm |
| Capacity that can be combined | 200ml/120ml * 1 |
| Temperature |
Setting range: -30-200 ° C * * 2 Adjustment accuracy: ± 0.5 ℃ ~ Display method: Digital LED display (Sample temperature display can be displayed by using optional temperature sensor) |
| Rotate |
Setting range: 50-1500rpm Stirring system: Genbal magnetic starler system Display method: Digital LED display |
| External temperature sensor | Shirokane measuring temperature resistor 1 connection (optional sensor) |
| Analog output | DC4-20ma |
| Reaction vessel | Can be observed from aluminum block slits |
| Safety features | Polycarbonate safety cover, drip receiving tray, overheated / super cool sensor |
| Mass | Approximately 5.1kg of the main unit and about 6.5kg |
| Program function | 9 steps x 9 patterns of temperature, time, stirring |
| Power Supply | AC100V 50/60Hz 5A |
| Size |
Body: 160 (W) x 300 (D) x 124 (H) mm Block part: 160 (W) x 350 (D) x 186 (H) mm |
| Accessories | Oval edge type φ16 × 38mm |
